Ball Type Check Valve

Ridhiman Alloys is a well-known supplier, stockist, manufacturer of Ball Type Check Valves in India

Ridhiman Alloys are Suppliers, stockist, and Exporter and Manufacturers of Ball Type Check Valves in India. Our high-quality range of Ball Type Check Valves is exclusively designed for chemical industries, steel factories, petrochemical industry, fire protection systems, paper manufacturing industries, shipping/shipment industries, etc. These are designed and developed in accordance with the international quality standards. Ball Type Check Valves that are precision engineered using the best quality raw material. We also customize Ball Type Check Valves as per the requirements of the clients.

Ball Type Check Valves Supplier, stockist, Manufacturer and Exporter in Mumbai Maharashtra India

We supply a wide range of precisely engineered Ball Type Check Valves, made in compliance with international quality and safety standards. Our Ball Type Check Valves are used for controlling the flow, pressure, temperature and liquid levels by fully or partially opening or closing the valve in response to signals received from the controller.

Table of Content

  • Information about Ball Type Check Valves
  • Features/Characteristics of Ball Type Check Valves
  • Advantages of Ball Type Check Valves
  • Connection type.

Types of Check Valves

  • DIN Lift Check Valves
  • Non-Slam Check Valves
  • Double Disc Check Valves
  • Tilting Disc Valves
  • Pressure Sealed Check Valves
  • Lift Wafer Check Valves
  • Swing Flex Check Valves
  • API Check Valves
  • API Single Disc Check Valves
  • Integrated Lug Type Check Valves

Wafer Type Ball Valve - Specification

DESCRIPTION STANDARD MATERIAL ON REQUEST
BODY/COVER CAST IRON (GG25) S.G.IRON(DI)/WCB/ST.STEEL
BALL NITRILE REINFORCED NEOPRENE/EPDM
SEAT RING L T BRONZE ST.STEEL
FASTENERS CARBON STEEL ST. STEEL
PAINT ENAMEL/EPOXY PAINT
END CONNECTION FLANGED

Wafer Type Ball Valve - Sizes, Pressure Rating

SIZE RANGE 25mm TO 350mm
PRESSURE TESTING BODY: 1.5 X PN
  SEAT : 1.1 X PN

PRESSURE RATING - KPa
25mm TO 125mm PN 1.6
150mm TO 300mm PN 1.0
350mm PN 0.6
INSTALLATION HORIZONTAL AS WELL AS VERTICAL
FACE TO FACE LENGTH IS 5312 PART I -1984/ DIN 3202-F6
TEMPERATURE SUITABLE UPTO 800C

About Ball Type Check Valves

Ball Type Check Valves was the first of the valve at Ridhiman Alloys with unique design and technology for the first time in India. There is no mechanism in this design, which makes it exceedingly simple and resilient. The rubber-coated ball is the heart of the valve. Normex has replaced the hinge-pin-disc mechanism used in traditional check valves with this rubber-coated ball to stop flow media in a return situation. they're utilized in Detergent, Pharmaceutical, Chemical, Rubber, Pulp and Paper Plants, Water Treatment Plants, Textile Mills and Food processing Plants. In general, Ball Type Check Valves provide several benefits when contrasted with different kinds of valves, they supply superior easy operation, which may maintain and regulate high volume, high and warm temperature flow. Most Ball Type Check Valves provide rugged construction providing with an extended time service life, and a comparable low price.

Applications and Uses of Ball Type Check Valves

  • Ball Type Check Valves used for Clean water.
  • Ball Type Check Valves used for Raw water.
  • Ball Type Check Valves used for Sewage, Slurry, Waste water.
  • Ball Type Check Valves used for Viscous liquids etc.
  • Ball Type Check Valves used in Sewage plants, Steel mills, Power stations and many more.
  • Ball Type Check Valves used in Chemical/process industries.
  • Ball Type Check Valves used in HVAC, Sugar/food industry, Breweries, Mining and many more.
  • Ball Type Check Valves used in Fire Water distribution, Water/Sewage treatment, Irrigation/agriculture.

Ball Type Check Valves Dimensions

Dimensions (A = Valve size in mm)
A 25 40 50 65 80 100 125 150 200 250 300 350
D 115 150 165 185 200 220 250 285 340 395 482 527
L 144 174 200 240 260 300 350 400 500 600 700 800
H 115 160 180 210 230 280 340 400 500 570 680 800
T 15 15 16 16 19 20 21 21 22 24 25 29
  • Additional Information:
  • Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer), Other
  • Port of Dispatch: Mumbai OR KALAMBOLI India
  • Packaging Details: Fitting are given marking, painted with black japan or black Board (Mat Finish) & will be packed in a bagging bag with stickers written with size, grade & quantity.

Ball Type Check Valves leading supplier, manufacturer, stockist in India – Ridhiman Alloys

Ridhiman Alloys is India’s most trusted Ball Type Check Valves supplier in India. Ridhiman Alloys have maintained to make a name in Ball Type Check Valves supplier in INDIA. Ridhiman Alloys is an ISO 9001:2008 certified company that has been in existence since 2007. Ball Type Check Valves are designed to control and help the flow of gases, liquids or other material.

Our manufactured Ball Type Check Valves contain prime quality materials. factory-made from quality grades meeting ASTM and/or AISI standards as a result of higher the standard, higher is that the toughness of the Ball Type Check Valves. prime quality of steel content makes a Ball Type Check Valves harder and will increase its hardness. Ridhiman Alloys is specialized in Supplier and stockists of Ball Type Check Valves in India. Ridhiman Alloys is a ISO certified Supplier and stockists in India. Ridhiman Alloys is widely common in India for its prime quality Ball Type Check Valves products.

Ball Type Check Valves Supplier stockist manufacturer exporter in Mumbai Maharashtra India

Ridhiman Alloys is world Leading stockists of Ball Type Check Valves.

Ridhiman Alloys Suppliers and Deal In solely quality tested Ball Type Check Valves. Ball Type Check Valves at Ridhiman Alloys bear several toughness and hardness check before provision it to our purchasers. we've over 99% happy purchasers.

Our purchaser’s satisfaction depends on a variety of things like quality, Toughness, Hardness, Delivery Time and our Services for Ball Type Check Valves. Ridhiman Alloys may be a Indian stockists of Ball Type Check Valves in INDIA. Ridhiman Alloys is also a leading stockist and Exporter and Manufacturer of other Type Check Valves such as control Check Valves, safety Check Valves, check Check Valves, ball Check Valves, butterfly Check Valves, etc in INDIA.

Ridhiman Alloys manufactures high quality, toughest and most durable Ball Type Check Valves. Due to our product quality the deamnd of our Ball Type Check Valves is rapidly increasing and to meet such high demands we have our sales offices in most of the India's cities:
